Cat NO

A1043

A1044

1045

A1046

A1047

  Clsaa ANSI

55-1

55-2

55-3

55-4

55-5

 Creepage Disance(mm)

102

127

178

229

305

   Dry Arcing Distance (mm)

57

86

114

127

159

 Cantilever Strength(KN)

13

11

11

13

13

 Low Frequency Dry Flashover voltage

35

45

56

65

80

Low Frequency Wet Flashover voltage

20

25

30

35

45

 Critical Impulse Flashover pos(kv)

50

70

90

105

130

 Critical Impulse Flashover Neg(kv)

70

85

110

130

150

 Power-Frepuency puncture voltage(kv)

50

70

90

95

115

  Test voltage to ground(kv)

5

5

10

10

15

Maximun RIV at 1000KHZ(μV)

50

50

50

50

100

 Net weight Eash APPROX(kg)

0.5

0.65

1

1.55

2.75

 Number in standard package

60

40

30

16

12
