No.

Type

Rated
voltage
?kV?

Rated
mechanical tension load
?kN?

Structure of
coupling
marks

Structure
height
?mm?

Min.Electric
arc distance
?mm?

Min nominal creepage
distance
?mm?

Full wave lightning
impulse withstand
voltage(peak value)
not less than?kV?

1min power frequency
wet withstand voltage
not less than?kV?

Nos of
voltage
divider ring

1

FXBW6-10/70

10

70

16

380±15

190

480

115

45

 N/A

2

FXBW4-35/70

35

70

16

650±15

470

1280

230

95

 N/A

3

FXBW4-35/100

35

100

16

670±15

450

1260

230

95

 N/A

4

FXBW4-66/70

66

70

16

940±15

700

1900

410

185

 N/A

5

FXBW4-66/100

66

100

16

940±15

685

1870

410

185

 N/A

6

FXBW4-110/70

110

70

16

1240±15

1035

3180

550

230

Negotiable

7

FXBW4-110/100

110

100

16

1240±15

1015

3150

550

230

Negotiable

8

FXBW4-220/100

220

100

16

2240±30

1950

6300

1000

395

Negotiable

9

FXBW4-220/160

220

160

20

2240±30

1950

6300

1000

395

Negotiable

10

FXBW4-330/100

330

100

16

2930±40

2550

9075

1425

570

Negotiable

11

FXBW4-330/160

330

160

20

2990±40

2600

9075

1425

570

Negotiable

12

FXBW4-500/160

500

160

20

4450±50

4000

13750

2250

740

Negotiable
